降低PHP Redis内存占用

时间:2017-04-08

散列分片主要是根据基础键以及散列包含的键计算出分片键ID,然后再与基础键拼接成一个完整的分片键。在执行hset与hget以及大部分hash命令时,都需要先将key(field)通过shardKey方法处理,得到分片键才能够进行下一步操作。

3.2、分片式集合

如何构造分片式集合才能够让它更节省内存,性能更加强大呢?主要的思路就是,将集合里面的存储的数据尽量在不改变其原有功能的情况下转换成可以被解析为十进制的数据。根据前面所讲到的,当集合中的所有成员都能够被解析为十进制数据时,将会采用intset存储方式,这不仅能够节省内存,而且还可以提高响应的性能。

例子:

假若要某个大型网站需要存储每一天的唯一用户访问量。那么就可以使用将用户的唯一标识符转化成十进制数字,再存入分片式set中。

#ShardSet.class.php

<?php
class ShardSet
{
  private $redis=''; #存储redis对象
  /**
  * @desc 构造函数
  *
  * @param $host string | redis主机
  * @param $port int  | 端口
  */
  public function __construct($host,$port=6379)
  {
    $this->redis=new Redis();
    $this->redis->connect($host,$port);
  }
  /**
  * @desc 根据基础键以及散列包含的键计算出分片键
  *
  * @param $base string | 基础散列
  * @param $key  string | 要存储到分片散列里的键名
  * @param $total int  | 预计分片总数
  *
  * @return string | 返回分片键key
  */
  public function shardKey ($base,$member,$total=512)
  {
    $shard_id=crc32($member)%$shards; #求余取模
    return $base.'_'.$shard_id;
  }
  /**
  * @desc 计算唯一用户日访问量
  *
  * @param $member int | 用户唯一标识符
  *
  * @return string | ok表示count加1 false表示用户今天已经访问过不加1
  */
  public function count($member)
  {
    $shardKey=$this->shardKey('count',$member,$total=10); #$totla调小一点用于测试
    $exists=$this->redis->sismember($shardKey,$member);
    if(!$exists)  #判断member今天是否访问过
    {
      $this->redis->sadd($shardKey,$member);
      $this->redis->incr('count');
      $ttl1=$this->redis->ttl('count');
      if($ttl1===-1)
        $this->redis->expireat('count',strtotime(date('Y-m-d 23:59:59'))); #设置过期时间
      $ttl2=$this->redis->ttl($shardKey);
      if($ttl2===-1)
      {
        $this->redis->expireat("$shardKey",strtotime(date('Y-m-d 23:59:59'))); #设置过期时间
        #echo $shardKey; #测试使用
      }
      #echo $shardKey;  #测试使用
      return 'ok';
    }
    return 'false';
  }
}
$str=substr(md5(uniqid()), 0, 8);  #取出前八位
#将$str作为客户的唯一标识符
$str=hexdec($str);   #将16进制转换为十进制
$obj=new ShardSet('192.168.95.11');
$obj->count($str);
?>

4、将信息打包转换成存储字节

结合前面所讲的分片技术,采用string分片结构为大量连续的ID用户存储信息。

使用定长字符串,为每一个ID分配n个字节进行存储相应的信息。

接下来我们将采用存储用户国家、省份的例子进行讲解:

假若某个用户需要存储中国、广东省这两个信息,采用utf8字符集,那么至少需要消耗5*3=15个字节。如果网站的用户量大的话,这样的做法将会占用很多资源。接下来我们采用的方法每个用户仅仅只需要占用两个字节就可以完成存储信息。

具体思路步骤:

1、首先我们为国家、以及各国家的省份信息建立相应的'信息表格'

2、将'信息表格'建好后,也意味着每个国家,省份都有相应的索引号

3、看到这里大家应该都想到了吧,对就是使用两个索引作为用户存储的信息,不过需要注意的是我们还需要对这两个索引进行相应的处理

4、将索引当做ASCII码,将其转换为对应ASCII(0~255)所指定的字符

5、使用前面所讲的分片技术,定长分片string结构,将用户的存储位置找出来(redis中一个string不能超过512M)

6、实现信息的写入以及取出(getrange、setrange)

实现代码:

#PackBytes.class.php

<?php
#打包存储字节
#存储用户国家、省份信息
class PackBytes
{
  private $redis=''; #存储redis对象
  /**
  * @desc 构造函数
  *
  * @param $host string | redis主机
  * @param $port int  | 端口
  */
  public function __construct($host,$port=6379)
  {
    $this->redis=new Redis();
    $this->redis->connect($host,$port);
  }
  /**
  * @desc 处理并缓存国家省份数据
  * @param $countries string | 第一类数据,国家字符串
  * @param $provinces 二维array | 第二类数据,各国省份数组
  * @param $cache 1/0  | 是否使用缓存,默认0不使用
  *
  * @return array | 返回总数据
  */
  public function dealData($countries,$provinces,$cache=0)
  {
    if($cache)
    {
      $result=$this->redis->get('cache_data');
      if($result)
        return unserialize($result);
    }
    $arr=explode(' ',$countries);
    $areaArr[]=$arr;
    $areaArr[]=$provinces;
    $cache_data=serialize($areaArr);
    $this->redis->set('cache_data',$cache_data);
    return $areaArr;
  }
  /**
  * @desc 将具体信息按表索引转换成编码信息
  *
  * @param $countries,$provinces,$cache| 参考dealData方法
  * @param $country string       | 具体信息--国家
  * @param $province  string      | 具体信息--省份
  *
  * @return string | 返回转换的编码信息
  */
  public function getCode($countries,$provinces,$country,$province,$cache=0)
  {
    $dataArr=$this->dealData($countries,$provinces,$cache=0);
    $result=array_search($country, $dataArr[0]); #查找数组中是否含有data1
    if($result===false)     #判断是否存在
      return chr(0).chr(0);  #不存在则返回初始值
    $code=chr($result);
    $result=array_search($province, $dataArr[1][$country]); #查找数组中是否含有data2
    if($result===false)
      return $code.chr(0);
    return $code.chr($result);   #返回对应ASCII(0~255)所指定的字符
  }
  /**
  * @desc 计算用户存储编码数据的相关位置信息
  *
  * @param $userID int | 用户的ID
  *
  * @return array | 返回一个数组 包含数据存储时的分片ID、以及属于用户的存储位置(偏移量)
  */
  public function savePosition($userID)
  {
    $shardSize=pow(2, 3);   #每个分片的大小
    $position=$userID*2;    #user的排位
    $arr['shardID']=floor($position/$shardSize);  #分片ID
    $arr['offset']=$position%$shardSize;   #偏移量
    return $arr;
  }
  /**
  * @desc | 整合方法,将编码信息存入redis中string相应的位置
  *
  * @param $userID int      | 用户ID
  * @param $countries string   | 第一类数据,国家字符串
  * @param $provinces 二维array | 第二类数据,各国省份数组
  * @param $country string       | 具体信息--国家
  * @param $province  string      | 具体信息--省份
  * @param $cache 1/0      | 是否使用缓存,默认0不使用
  *
  * @return 成功返回写入位置/失败false
  */
  public function saveCode($userID,$countries,$provinces,$country,$province,$cache=0)
  {
    $code=$this->getCode($countries,$provinces,$country,$province,$cache=0);
    $arr=$this->savePosition($userID); #存储相关位置信息
    return $this->redis->setrange('save_code_'.$arr['shardID'],$arr['offset'],$code);
  }
  /**
  * @desc 获取用户的具体国家与省份信息
  *
  * @param $userID int | 用户ID
  *
  * @return array | 返回包含国家和省份信息的数组
  */
  public function getMessage($userID)
  {
    $position=$this->savePosition($userID);
    $code=$this->redis->getrange('save_code_'.$position['shardID'],$position['offset'],$position['offset']+1);
    $arr=str_split($code);
    $areaArr=$this->dealData('', '',$cache=1); #使用缓存数据
    $message['country']=$areaArr[0][ord($arr[0])];
    $message['province']=$areaArr[1][$message['country']][ord($arr[1])];
    return $message;
  }
}
header("content-type: text/html;charset=utf8;");
$countries="无 中国 日本 越南 朝鲜 俄罗斯 巴基斯坦 美国";
$provinces=array(
    '无'=>array('无'),
    '中国'=>array('无','广东','湖南','湖北','广西','云南','湖南','河北'),
    '日本'=>array('无','龟孙子区','王八区','倭国鬼区','鬼子区','萝卜头区'),
  );
$obj=new PackBytes('192.168.95.11');
/*
#数据处理,并将其缓存到redis中
$b=$obj->dealData($countries,$provinces);
echo "<pre>";
print_r($b);
echo "</pre>";die;
*/
/*
#存储用户国家省份信息
$country='中国';
$province='广东';
$result=$obj->saveCode(0,$countries,$provinces,$country,$province);
echo "<pre>";
print_r($result);
echo "</pre>";
*/
/*
#取出用户国家省份信息
$a=$obj->getMessage(15);
echo "<pre>";
print_r($a);
echo "</pre>";die;
*/
?>

测试:

1、dealData处理后的信息,即为'信息表表格'

2、saveCode()
